| General Information | Shell material | Metal |
| Lens (focal length) | 2.8mm | |
| Lens (angle) | 70 degrees（Plus or minus 5 degrees） | |
| Horizontal resolution | 700TVL | |
| Pixels (effective resolution) | 800*480 | |
| Minimum illumination | LOW illumination below 0.013LUX automatically opens. | |
| Viewing angle | 120 degrees（Plus or minus 5 degree | |
| Signal to noise ratio | Greater than 43.1db | |
| Wiring por | 4pin aviation head & RCA | |
| Power supply (wide voltage) | DC12V-24V/60, MA±5MA | |
| Power consumption | Infrared synchronization,Video lightning protection,Power consumption is less than 2W | |
| Working temperature | Minus 20 to 75 degrees | |
| Day and night mode | External control(Default)/Automatic/Chromatic/Monochrome | |
| Whether night vision | Support | |
| Night vision distance | 8-10M | |
| Infrared distance | 8-10M | |
| Number of infrared lights | Twelve | |
| Waterproof grade | Non-waterproof | |
| Irradiation directio | Adjustable | |
| Available Color | （ BLACK）（GRAY）（WHITE） | |
| Accessories | 1 x 3 Mounting screws | 1 x Product Qualification Certificate |
