Model |
QW-EX-MA/S |
|
|
Certificate |
||
|
explosion-proof sign |
ExdⅡCT6Gb/ExtD A21 IP68 T80℃ |
|
|
Mechanical property |
||
|
Material |
aluminium alloy shell |
|
|
level of protection |
IP68 |
|
|
Installation |
Ceiling mounted, wall mounted |
|
|
Electrical performance |
||
|
Input voltage |
DC12V |
|
|
Working current |
≤1A |
|
|
|
Resolution |
200W |
|
|
Lens |
3.6mm |
|
|
SNR |
＞52db |
|
|
Minimum illumination |
0Lux(infra-red on) |
|
Infrared |
Distance |
8-15m |
|
|
Wave length |
850nm |
|
|
Switch |
Auto(≤10Lux) |
|
Connector |
Aerohead |
|
|
Environment |
||
|
Operating temperature |
（-30℃，+85℃） |
|
|
Barometric pressure |
80-106KPa |
|
|
Relative humidity |
≤95%RH(+25℃) |
|
